Applications
Features
- Custom 350W Cold White LED Engine (6500K)
- 21,000 lumens through its 140 mm (5.5 in) front lens
- Its refined, center-peaked hotspot ensures crisp gobos, sharp mid-air effects, and consistent beam quality, even over long distances, ideal for arena side-keys, gobo projection, and precise aerial work
- 3.8°–47.2° linear zoom
- Its powerful effects engine includes CMY with linear CTO, dual gobo and animation wheels, prisms, iris, and 5°/1° frosts, while GoBright optimization maintains maximum brightness and color integrity
- Advanced Four-Focal-Planes Shutter System with independently adjustable blades, delivering precise beam shaping, smooth transitions, and the dramatic Total Curtain effect
Specifications
Light source
custom 350W cold white LED engine (6500K)
Source type
Cold White LED
Color temperature
6500 K ± 300K
CRI
Up to 70 with selectable filter for CRI up to 88
Zoom range
3.8° - 47.2°
Lumen
21.000 Lm (integrating sphere)
Protocols
DMX, Art-Net, sACN, RDM
Power con
PowerCon True1 IN/OUT
Colour mixing
Linear CMY/CTO
Colour Wheel
1 color wheel with 6 dichroic colors, tint channel
Framing Systems
4 blades (± 35° inclination) with ± 60° rotation of the full system
Gobos
1 static gobo wheel with 9 dichroic fixed interchangeable gobos • 1 rotating gobo wheel with 7 interchangeable glass gobos
