Arolla Aqua S-LT logo

Long-throw IP66 LED profile moving head — 21,000 lm and a 3.8°–47.2° zoom from a 350 W engine.

Applications

Features

  • Custom 350W Cold White LED Engine (6500K)
  • 21,000 lumens through its 140 mm (5.5 in) front lens
  • Its refined, center-peaked hotspot ensures crisp gobos, sharp mid-air effects, and consistent beam quality, even over long distances, ideal for arena side-keys, gobo projection, and precise aerial work
  • 3.8°–47.2° linear zoom
  • Its powerful effects engine includes CMY with linear CTO, dual gobo and animation wheels, prisms, iris, and 5°/1° frosts, while GoBright optimization maintains maximum brightness and color integrity
  • Advanced Four-Focal-Planes Shutter System with independently adjustable blades, delivering precise beam shaping, smooth transitions, and the dramatic Total Curtain effect

Specifications

Light source

custom 350W cold white LED engine (6500K)

Source type

Cold White LED

Color temperature

6500 K ± 300K

CRI

Up to 70 with selectable filter for CRI up to 88

Zoom range

3.8° - 47.2°

Lumen

21.000 Lm (integrating sphere)

Protocols

DMX, Art-Net, sACN, RDM

Power con

PowerCon True1 IN/OUT

Colour mixing

Linear CMY/CTO

Colour Wheel

1 color wheel with 6 dichroic colors, tint channel

Framing Systems

4 blades (± 35° inclination) with ± 60° rotation of the full system

Gobos

1 static gobo wheel with 9 dichroic fixed interchangeable gobos • 1 rotating gobo wheel with 7 interchangeable glass gobos
